Product Features • High-Resolution Color Touchscreen LCD — 10.1” high-resolution color touchscreen LCD that displays up to 12 leads of ECG data for immediate review and plotting. • Distinguished VERITAS® Resting ECG Interpretation Algorithm — Widely recognized interpretive algorithm uses gender-specific, adult and pediatric criteria to provide a silent second opinion for resting ECG interpretation. Displays hook-up confirmation, which includes detection of lead reversals. • Data Security — Securing ePHI is promoted with centralized device access controls that are integrated with LDAP or Active Directory service. Additionally, encryption both at rest and in transit protects ePHI from the ELI 280 ECG to the server. • Choice of Wireless or Traditional ECG Acquisition — The ELI 280 ECG offers a choice of either the WAM™ wireless acquisition module or the AM12™ acquisition module. Both include individual replaceable lead wires, lead fail indicator and remote control with buttons for ECG acquisition and rhythm printing. • Best 10 — The ELI 280 ECG evaluates ECG signal and noise to determine and select the 10 seconds of data with the least amount of noise. Best 10 simplifies ECG acquisition by reducing clinical review time and eliminating the need for repeat ECGs. • Information Exchange — Bidirectional communication via LAN or wireless LAN enables connectivity to Pyramis®, HeartCentrix®, E-Scribe™ and Athena products, as well as to third-party EHR, PACS and CVIS systems using XML/PDF formats and DICOM/HL7 protocols. The device also communicates to the ECG Safe™ system, a cloud-based service that provides an easy, effective way to store ECGs for convenient
viewing and file management from anywhere.
ELI 280 Electrocardiograph Feature Specification* Instrument Type Multi-lead electrocardiograph Input Channels Simultaneous acquisition of all 12 leads Standard Leads Acquired I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6 Waveform Display Backlit, 10.1” high-resolution color LCD Input Impedance Input Dynamic Range Electrode Offset Tolerance Common Mode Rejection Meets or exceeds the requirements of ANSI/AAMI EC11 Patient Leakage Current Chassis Leakage Current Meets or exceeds the requirements of ANSI/AAMI ES1 Digital Sampling Rate 40,000 samples/second/channel used for pacemaker spike detection; 1,000 samples/second/channel used for recording and analysis Optional Functions Connectivity with bidirectional communication; SECUR-it; exercise stress (check local availability) Paper A4 (210 x 297 mm), perforated Z-fold thermal paper, 250 sheets, or Smart (210 x 280 mm), perforated Z-fold thermal cued paper with full grid, 250 sheets, or US letter (8.5 x 11”), perforated Z-fold thermal paper, 250 sheets Thermal Printer Computer-controlled dot array; 1 dot/ms horizontal, 8 dots/mm vertical Thermal Printer Speeds 5, 10, 25, or 50 mm/s Gain Settings 5, 10, or 20 mm/mV Report Print Formats Standard or Cabrera: 3+1, 3+3, 6, 6+6, or 12 channel Rhythm Print Formats 3, 6, 8 or 12 channel with configurable lead groups Keyboard Touchscreen keyboard with alphanumeric keys, soft-key menu and dedicated function keys Frequency Response 0.05 to 300 Hz Filters High-performance baseline filter; AC interference filter 50/60 Hz; low-pass filters 40 Hz, 150 Hz, or 300 Hz A/D Conversion 20 bits (1.17 microvolt LSB) Device Classification Class I, Type CF defibrillation-proof applied parts ECG Storage Internal storage up to 200 ECGs SECUR-it Requires software version 2.0.0 or greater Requires ELI Link software version 4.4.0 or greater Weight 16.30 kg (3.9 lbs.) including battery (without paper) Dimensions 39.4 x 43.2 x 10.2 cm (15.5 x 17 x 4” Power Requirements Universal AC power supply (100-240 VAC at 50/60 Hz) 110 VA; internal rechargeable battery
